Aura Premium
All In One Max Series R32
The fully integrated All-In-One solution for your home. Heat pump, 230-L domestic hot water tank and 70-L buffer tank combined in a single elegant indoor unit — for maximum efficiency, comfort and minimal footprint.
Key Features
Everything your home needs — united in a single indoor unit.
All-In-One Max Compactness
230-L domestic hot water tank (DHW) and 70-L buffer tank (BIF) in a single slim indoor unit. Saves plant room space, simplifies hydraulic connections and dramatically reduces installation time.
Up to 60°C Water Temperature
High flow temperatures for existing buildings with radiators or higher domestic hot water demand. The R32 circuit maintains a stable 60°C outlet — even at -20°C ambient temperature.
Legionella Prevention
Integrated DHW disinfection programme automatically heats the storage tank to 55–57°C. Prevents legionella growth — hygienically safe hot water at all times.
Solar Heat Integration
Integrated solar collector circuit connection for eco-efficiency and free hot water. Seamless integration of solar thermal or gas boiler as supplementary source — future-proof system architecture.
Climatelink™ Smart Control
Central control system integrating wiring and Wi-Fi connectivity. All functions, system settings and fault diagnostics via the intuitive colour touchscreen and Climatelink™ app.
SUS-316L Stainless Steel
Corrosion-resistant SUS-316L steel, INCOLOY heater and magnesium anode guarantee hygienic water quality and decades of reliable operation with minimal maintenance.
System Architecture
The Aura split system consists of an outdoor unit and an indoor unit — available in three configurations.
Hydrobox
Slim indoor unit with optimised hydraulic connections for heating, cooling and hot water. Ideal for systems with a separate hot water cylinder.
All-In-One (190 / 230 L)
190-L or 230-L hot water tank integrated. Compact design with intuitive touchscreen, SUS316L, backup heater and magnesium anode.
All-In-One Max ← This Page
230-L DHW + 70-L buffer tank in one elegant indoor unit. Quick-access design, SUS316L, solar collector circuit, backup heater and magnesium anode.
Technical Data
Specifications for the Aura Premium All In One Max R32 (outdoor unit + All-In-One Max indoor unit).
| System Type | Split system (outdoor + indoor unit) |
|---|---|
| Refrigerant | R32 (GWP = 675) |
| Outdoor Unit Capacities (R32) | 7 kW (single-phase) / 9–12 kW (three-phase) / 17–22 kW (three-phase) |
| Max. Water Outlet Temperature | 60°C (R32) |
| Heating Operating Range | Down to -20°C ambient (without backup heater) |
| Indoor Unit Configuration | All-In-One Max |
| Hot Water Tank (DHW) | 230 litres (integrated) |
| Buffer Tank (BIF) | 70 litres (integrated) |
| Tank Material | SUS-316L stainless steel |
| Heating Element | INCOLOY (integrated) |
| Magnesium Anode | Yes |
| Solar Collector Circuit | Integrated |
| Legionella Prevention | Automatic DHW disinfection programme (55–57°C) |
| Control | Central colour touchscreen (Climatelink™) |
| Connectivity | Climatelink™ Wi-Fi (app + web dashboard) |
| Indoor Unit Dimensions (W×D×H) | 880 × 720 × 1984 mm |
| Total Storage Volume | 230 + 70 = 300 litres |
| Certifications | CE, ErP |
| Awards | Red Dot Award 2023, Japan Good Design Award 2023 |
Interested in the Aura Premium All In One Max R32?
Contact us for an individual quotation or technical consultation on the optimal system configuration.
